HMDR-60|HMDR-80|HMDR-100

Innovation - at Work

Stacking made easy with the 'Ezi' Electric Stackers from 'JAY' ideal for operation in narrow aisles and gangways…

Request More Information

Product Overview

Hydraulic Mobile Dock Ramp HMDR-60 | HMDR-80 | HMDR-100 M1 are designed to provide maximum productivity for Container | Truck loading/unloading operation.

With the help of this equipment forklift can go right inside the container for loading/unloading of material and helps in reducing manpower and reduce damages.

The equipment is manufactured with heavy robust structure to provide maximum safety during operations. Hydraulic Mobile Dock Ramp are mobile equipment which can be moved to free loading space once the work is completed.

Specifications

HMDR-60 | HMDR-80 | HMDR-100 M1

Hydraulic Mobile Dock Ramp are equipped with hydraulic cylinder for aligning the height with container|truck for smooth and easy operations. The equipment is also provided with floor locks for extra safety.

Load Capacity 6000 | 8000 | 10000 kgs
Max. Platform size [LxW] 10000 x 2200mm
Max. Raised ht 1700mm
Max.Lowered ht 1200mm
Controls Hand Pump Operated
Wheels Rubber Tyres
Download Specifications

Features

Dumy content heading change soon..

  • Easy Operations
  • Heavy Duty Structure
  • A movable loading|unloading equipment
  • Adjustable equipment heights.

Easy Hand Pump Operations

Floor Locks for extra safety

Heavy duty Lip

Foldable ramp for easy manoeuvrability
